ClassicX Series

3, 5 Layer Cast PP Film (CPP) Extrusion Machine

ClassicX cast PP film (CPP) extrusion machine line is Jinming's high-intellectualized and high-performance series with features of high-output, high-automatization and superior thickness deviation, etc.. Besides, ClassicX has a good adaptability of resins, which meets customers' needs on high quality and high output.

Application

Parts Introduction

Feed Block & T-die

The feed block and T-die adopt floating layer designing with extrusion capacity is adjustable. They have short 3D melt channels without dead angle. Through melt analysis and simulation system, it will ensure the T-die has even thickness distribution of each layer and good performance on extruding speed.

Feed block & T-die device of 3-5 layer cast PP film (CPP) line

Roll Temperature Control System

It is a modular and general designing, which is applicable for various production line. It uses independent control system for roll heating and cooling so it can reduce film roll deformation. The cooling system is recyclable so it can reduce water consumption.

Roll temperature control system of 3-5 layer cast PP film (CPP) line

Turret Winder

It uses fully automatic turret structure, integrated with surface, center and gap winding. It has function of automatic loading, film cutting, reel changing, unloading, meter counting etc. Film unloading is controlled by hydraulic system. It equips with constant tension control system which can automatically chase film position by its surface tension then improve winding flatness.

Equipment Exhibition

The 3-5 layers cast PP film (CPP) extrusion machine display, including feed block & T-die, roll temperature control system, and turret winder.

Turret winder of 3-5 layer cast PP film (CPP) line

Technical Parameter

Please select the one you need into the inquiry cart
Model
Die lip size
Film width
Film thickness
For processing of
Screw Diameter
Line Speed
Throughput
Total Power
Dimension
3500mm 4850mm 5500mm
3200mm 4550mm 5200mm
0.02~0.10mm 0.02~0.10mm 0.02~0.10mm
PP PP PP
Φ90/160/90mm Φ150mm×4 Φ150/160/160/150mm
300m/min 250m/min 250m/min
1000kg/H 2200kg/H 2700kg/H
1100kVA 1700kVA 2000kVA
26x13x8m 27x14x8.5m 30x14x8m
